REW Beta Release REW API beta releases

[John Mulcahy]

Builds updated today (beta 78) with these changes:

• Added: Burst decay waterfall and spectrogram plots have more octave fraction choices
• Changed: Equalisers that run at the rate of the measurement (e.g. Generic) will default to the REW sample rate when no measurements are loaded
• Changed: Longer measurement names are allowed, but the name will be truncated if necessary in graph legends
• Fixed: Setting a toneburst with a burst length longer than the burst period caused an error
• Fixed: Alignment tool phase traces were plotted red if the alignment tool smoothing differed from the measurement smoothing
• Fixed: Measurement names might be truncated in the overlay view selectors used by All SPL and the Overlays window
• Fixed: Stepped IMD plots used total input RMS as the reference level for dBr and percent instead of the relevant reference for the IMD measure
• Fixed: The measurement name preview on the Measure dialog did not enforce the name length limit, name preview now turns red if name is too long and will be truncated
• Fixed: API commands to make a measurement did not check that measurement was possible
• Fixed: API changes to the default target settings might be overridden by GUI components
• Fixed: House curve file set through the API was not remembered for the next startup
• Fixed: API gets that should return String values returned the string as a message field, affecting the following endpoints:
  • /alignment-tool/uuid-a
  • /alignment-tool/uuid-b
  • /eq/house-curve
  • /import/sweep-recordings/stimulus
  • /import/sweep-recordings/response
  • /import/frequency-response
  • /import/frequency-response-data
  • /import/impulse-response
  • /import/impulse-response-data
  • /import/rta-file
  • /measure/notes
  • /measure/measurement-mode
  • /measure/filtered-spl-filter-source-uuid
  • /measure/playback-mode
  • /measure/file-playback-stimulus
  • /measure/timing/reference
  • /measure/timing/reference/none/tzero
  • /measurements//selected-uuid
  • /rta/y-axis
  • /stepped-measurement/type



[Nicoo]

Hi John,

Have been trying all the afternoon to get it working on my end (Denon 4700H with Audyssey App and A1 Evo) but keep having the same error from A1 Evo (both on my Windows PC and Mac).

[WARNING!] Target curve not found! Browse to and select 'TargetCurve_MJ.txt' (or any other) in 'REW / EQ window / House curve'!

However, I confirm that I did include this file coming straight from A1 Evo into the House curve field as shown below.

Any idea on what I am doing wrong here?

Thanks a lot for your help!!



[John Mulcahy]

The release fixed a bug affecting the way some endpoints, including the house curve endpoint, return String values. The A1 script probably needs an update to account for that.



[Nicoo]

Appreciate the express response here!

Is there a way to get access to the previous version by chance?



[John Mulcahy]

The files, including some earlier beta builds, are at https://www.roomeqwizard.com/installers/



[Nicoo]

Works! Thanks a lot again!



[serko70]

Sorry to hijack the REW Beta thread but to avoid further queries:

A1 Evo Acoustica v3.2 has been uploaded and is fully compatible with REW Beta 78 (and no longer compatible with any lower REW versions).

Thanks.
